Description
- 6 burner cooktop
- 2/1 GN electric convection oven
- Heavy?duty construction
- 28 MJ/hr open burners
- Flame failure standard
- Available in Natural Gas & LPG
- Units supplied complete with gas type conversion kits
- Pilot burners optional
- Optional simmer plates
- Stainless steel exterior
- Easy to clean
- Easy service
- Fully modular
- Overall Construction ? Cooktop
- Galvanized steel chassis
- Welded hob with 1.5mm 304 stainless steel bull nose
- Splashback and hob sides 1.2mm 304 stainless steel
- Front panels and oven sides 0.9mm 304 stainless steel
- Aluminised steel internal construction
- Cast iron 28MJ/hr open burners with forged brass cap
- Vitreous enamelled cast iron potstands
- Vitreous enamelled open burner spill covers
- Vitreous enamelled spill trays
- Oven
- 50?320°C thermostatic control
- Indicator lights for power and heating
- Fully welded and vitreous enamelled oven liner
- GN 2/1 capacity with 4 position racking
- Easy remove heavy wire chrome rack supports
- Cast iron even heat oven sole plate
- 6.5kW heating elements
- 100W heavy?duty motor
- Heavy?duty circulation fan
- Welded frame drop down door
- Heavy?duty spring hinge system
- High density fibreglass insulated
- Stay cool stainless steel door handle
- Supplied with 2 chrome wire oven racks
- Controls
- Large easy use control knob
- Heat resistant reinforced
- Easy view control settings on knob
- Variable high to low controls to open burners
- Variable high to low controls to griddles
- Piezo ignition
- Cleaning and Servicing
- All models with easy clean stainless steel external finish
- Lift off burner heads
- Vitreous enamelled burner spill covers
- Removable bottom sill
- Removable oven racking and sole plate
- Easy clean vitreous enamel oven and door inner
- Adjustable door hinge spring
- All parts front accessible from installed position
- Access to all parts from front of unit
- Standard splashback or Low Back models available
- Low Back models are non-stocked items
- Warranty: 12 months Parts & Labour
- Maximum Gas: 168 MJ/hr; 46.6 kW
- Dimensions: 900 x 805 x 915 [h]
- Nett weight: 200 kg
